Off-road electric scooter
Kaabo Mantis 10 ECO
Conquer Any Terrain.
Specifications of
Kaabo Mantis 10 ECO
Motor | |
---|---|
Drivetrain | Rear drive |
Nominal Power | 800 W |
Maximum Power | 1.600 W |
Speed | |
Limited Speed | 25 km/h |
Speed Modes | Eco / Turbo, Single / Dual |
Maximum Incline Angle | 30% |
Battery | |
Maximum Range | 70 km |
Battery Capacity | 18.2 Ah |
Battery Voltage | 48 V |
Charging Time | 9 hours |
Charger Type | 1x Standard charger |
Suspension | |
Front Suspension | Spring adjustable |
Rear Suspension | Spring adjustable |
Brakes | |
Front Brake | Hydraulic disc brake + EABS |
Rear Brake | Hydraulic disc brake + EABS |
Tires | |
Tire Type | Pneumatic |
Front Wheel Size | 10" |
Rear Wheel Size | 10" |
Lighting | |
Front LED light, Rear lights, Turn Signals | |
Water Protection | |
IPX5 - Protected from low-pressure water spray | |
Dimensions | |
Length | 1267 mm |
Height | 1230 mm |
Width | 560 mm |
Folded | |
Length | 1267 mm |
Height | 480 mm |
Width | 560 mm |
Other | |
Recommended Height | 160-200 cm |
Net Weight | 24 kg |
Load Capacity | 120 kg |
Warranty | 1 year |
-
Comfort & Design
The Kaabo Mantis 10 ECO ensures a remarkably smooth and comfortable ride, thanks to its signature front and rear adjustable spring suspension system. This setup expertly mitigates impacts from rough surfaces. The ride quality is further enhanced by large 10x3.0-inch pneumatic tires, which offer superior grip and shock absorption. The scooter features the new, multifunctional Kaabo display, providing clear at-a-glance ride data and includes an NFC card reader for convenient, keyless locking and unlocking.
-
Maintenance
Engineered for reliability, the Kaabo Mantis 10 ECO requires minimal and straightforward maintenance. Owners should perform regular inspections of tire pressure to ensure optimal performance and safety, check the integrity of the hydraulic brake system, and verify that all essential bolts are securely fastened. The scooter's high-quality construction and durable components are designed for longevity, reducing the need for frequent servicing and ensuring this electric scooter remains a dependable part of your daily routine.
